Product specifications:

Electrical Specifications

Voltage: 38.4V
Nominal capacity: 100Ah
Nominal Energy: 3840Wh
Cycle life: ≥4000 times

Mechanical Specifications

Dimension(LXWXH): 522X240X218mm
Weight: 36Kg
Cell type/Chemistry: Prismatic LiFePO4
Terminals: standard Screw terminals

Charge&Discharge Specifications

Charge method: CCCV
Charge voltage: 42.6 - 43.8V
Max. Charge current: 100A
End of discharge voltage: 27V
Discharge current continuous: 100A
Peak current: 300A

Temperature Specifications

Charge temperature: 0℃~45℃
Discharge temperature: -20℃~60℃
Storage temperature: 15~+35℃

Compliance specifications:

Certification: RoHs, CE
Shipping method: Expressage, by Sea, by Railway, by Air

Compliance specifications:

The battery can be in series in 4 or in parallel in 4, but not at the same time.
